Application: Suitable for pumps, hydraulic equipment, pneumatic equipment, machinery and process systems.
Lens: Tempered glass (standard)
Material for case: SS304
Material for welded part: SS316, Brass
Housing enclosure: IP65
Dial size: Ø 2.5”, 4”, 6”, 8” available
Connection type: Back and bottom available
Thread type: Standard ½”NPT, ½”BSP, ¼”NPT, ¼”BSP available
Over-pressure limit: 30% of full scale value
Accuracy: ±1.0% to ±2.5%
Ambient/Process temperature: -40°C to 65°C (dry); -10°C to 65°C (glycerine filled)
Optional: Safety laminated glass, glycerine, silicone filling, third party calibration certificate.
